3-10 Dell PowerEdge 4100/180 and 4100/200 Systems Installation and Troubleshooting Guide
Table 3-4. SCSI Hard-Disk Drive Indicator
Patterns
Condition Indicator Pattern
Identify drive All three drive status
indicators blink simulta-
neously.
Drive being prepared
for removal
The three drive status
indicators are flashed
sequentially.
Drive ready for inser-
tion or removal
All three indicators are off.
Drive being prepared
for operation
The drive online indicator is
on. The drive activity light
may flash briefly.
Drive bay empty All three indicators are off.
Drive predicted fail-
ure
The drive online indicator
turns off. The drive fault
indicator blinks on briefly
each second.
Drive failed The drive online indicator
turns off. The drive fault
indicator blinks off briefly
each second.
Drive rebuilding The drive online indicator
blinks rapidly.
Drive online The online indicator is on.
