8-2 Dell PowerEdge 4100/180 and 4100/200 Systems Installation and Troubleshooting Guide
E
xpansion Cards
This computer can hold up to eight expansion cards, five
of which can be 32-bit PCI cards. The system accommo-
dates a mix of 32-bit EISA master or slave cards, 32-bit
PCI cards, and 8- and 16-bit ISA cards. Figure 8-2 shows
examples of the different types of expansion cards.
The system board contains a total of eight expansion-card
connectors. An opening is available in the back panel of
the computer for each expansion-card connector, thus
providing eight usable expansion slots.
Figure 8-2. Expansion Cards
16-bit ISA expansion card
32-bit EISA expansion card
32-bit PCI expansion card
8-bit ISA expansion card
