Dell 5820 - Hardware Connectivity and Storage Support; Avid I;O Hardware Support

Page 4 of 14
Dave Pimm – Avid Technology – Dec 22, 2017
Rev A
3.) Qualified O.S., Hardware and shared storage supported:
Qualified / Supported
Nitris DX / Mojo DX
NOT SUPPORTED
(requires PCIe gen 1 or 2 slot which is not
available on this system)
Artist DNxIO/ DNxIQ (PCIe or
thunderbolt connection)
Artist DNxIV (thunderbolt only
connection)
Yes – Supported
PCIe Guidance
PCIe preferred as it requires less system over-head due
to direct PCIe to PCIe connection between the host
CPU and Artist DNxIO.
Thunderbolt Guidance
Thunderbolt 2 & 3 - higher system over-head, not
recommended to share Thunderbolt devices on the
same Thunderbolt bus with DNxIO, DNxIQ, DNxIV
DELL 5820 supports only one Thunderbolt 3 HBA with
dual Thunderbolt 3 ports.
DNxIO would require TB3 to TB2 converter
Thunderbolt 3 offers support of cable lengths up to
60-meters (via qualified Corning Thunderbolt cables)
for users needing to physically place the Artist DNxIO
at longer distances from the host CPU Workstation.
3
rd
Party Qualified Hardware
See release notes and Avid website for
information regarding supported 3
rd
party
hardware (vendor qualified)
NEXIS / ISIS Single 1Gb Ethernet Client
NEXIS Dual 1Gb Ethernet Client
Intel i350, i219, i210
ISIS 5500 / 5000 , 7500 / 7000
NEXIS Pro, E2, E4, E5 V7.9
NEXIS / ISIS Hi-res (single 10Gbit) client
Myricom Single-Port 10Gbit
Atto FFRM-NS1, Intel X710
ISIS 5500 / 5000 , 7500 / 7000
NEXIS Pro, E2, E4, E5 V7.9
NEXIS / ISIS Ultra Hi-res (dual 10Gbit)
Myricom Dual-Port 10Gbit
Atto FFRM-NS2, Intel X710
ISIS 5500 / 5000
NEXIS Pro, E2, E4, E5 V7.9
