Video
Table 8. Discrete graphics specifications
Discrete graphics
Controller External display support Memory size Memory Type
NVIDIA GeForce RTX 2080 One HDMI port and one DisplayPort 8 GB GDDR6
NVIDIA GeForce RTX 2080
Ti
One HDMI port and one DisplayPort 11 GB GDDR6
Audio
Table 9. Audio specifications
Description Values
Type
Integrated 7.1 channel audio with S/PDIF port
Controller
Realtek ALC3861
Internal interface
High-definition audio
External interface
7.1 channel output, Microphone-in, stereo headphones, and
headset combo connector
Storage
Your computer supports one of the following configurations:
• One M.2 2242/2260/2280 solid-state drive, one 3.5-inch hard drive, and two 2.5-inch hard drives
• One U.2 drive and two 2.5-inch hard drives
• One 3.5-inch hard drive and two 2.5-inch hard drives
NOTE: The primary drive of your computer varies depending on the storage configuration.
Table 10. Storage specifications
Form factor Interface type Capacity
Two 2.5-inch hard drives SATA AHCI 6 Gbps Up to 2 TB
One 3.5-inch hard drive SATA AHCI 6 Gbps Up to 1 TB
One M.2 2242/2260/2280 solid-state drive • SATA AHCI 6 Gbps
• PCIe NVMe up to 32 Gbps
Up to 1 TB
Power ratings
Table 11. Power ratings specifications
Type
460 W 850 W
Input voltage
90 VAC to 264 VAC 90 VAC to 264 VAC
Input frequency
47 Hz to 63 Hz 47 Hz to 63 Hz
Input current (maximum)
8 A 8 A
14
