About Your Display | 11
7 USB 3.0 downstream
ports (3)
Connect your USB device.
You can only use this connector after you have connected
the USB cable to the computer and USB upstream
connector on the display.
8 USB charging port USB 3.0 with 10 W with BC1.2 charging capability at 2A
(max).
9 RS232 connector Remote management and control of display via RS232.
10 RJ-45 connector Remote Network Management and control of display via
RJ-45.
Input sources and USB pairing
CEC
Input sources USB upstream
HDMI 1 CEC USB 1
HDMI 2 USB 2
HDMI 3
USB 3DP
VGA
Bottom View
2 31
Label Description
1, 2 Speakers
3 Power on/off button
