Installing system fan
Steps
1. Connect the speaker cable and system fan cable to the connectors on the system board.
2. Place the system fan on the computer and slide the system fan until it clicks into place.
3. Install the cover.
4. Follow the procedure in After working inside your computer.
Speaker
Removing speaker
Steps
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. cover
b. system fan
3. To remove the speaker:
a. Release the speaker cable from the retention hooks on the system fan [1].
b. Remove the M2.5X4 screws that secure the speaker to the system fan [2].
c. Remove the speaker from the system fan [3].
Removing and installing components
19

Dell D10U Specifications

General

Model	D10U
RAM Technology	DDR3
Operating System	Windows 7
Optical Drive	DVD-RW
USB Ports	6 (2 front, 4 rear)
Network	Gigabit Ethernet
Storage	HDD
