Dell D11S004 - Installing the Power Supply Unit or PSU

Installing the power supply unit or PSU
1 Insert the PSU in the chassis and slide it towards the back of the system to secure it [1].
2 Replace the screws to secure the PSU to the rear chassis of the system .
Removing and Installing components
67
