9 To install the hard drive and optical drive module:
a Insert the tabs on the hard drive and optical drive module into the slot on the system at a 30-degree angle [1].
b Connect the optical drive data cable and power cable to the connectors on the optical drive [2, 3].
c Lower the hard drive and optical drive module so that it is placed in its slot [4].
