Dell DA305 - Page 8

8
4. The DA305 supports power delivery pass-through up to 90W when connected
to the Thunderbolt or USB-C (Display Port Alt Mode) port of your PC.
Power can be supplied by the USB-C power adapter or USB-C monitor with
power delivery capability that supports charging feature. The following two
images show DA305 connected to an external power source via USB-C power
adapter or USB-C monitor.
NOTE: DA305 can support only one display at any given time.
With Power Delivery Pass-Through Via USB-C Power Adapter
With Power Delivery Pass-Through Via USB-C Monitor
2 Display out (Choose 1)
USB-C
USB-C
Dual USB-A
Dual USB-A
Dual USB-A
Dual USB-A
USB-C Power Adapter
