Externally accessible:
Serial
9-pin connector; 16550C-compatible
Parallel
25-hole connector (bidirectional)
Video
15-hole connector
Keyboard
6-pin mini-DIN connector or USB connector
Mouse
6-pin mini-DIN connector or USB connector
USB
two front-panel and two back-panel USB–compliant
connectors
Headphone
front-panel miniature connector
Audio
2
three miniature connectors for line in, line out, and
microphone
Internally accessible:
Primary IDE channel
40-pin connector on PCI local bus
Secondary IDE channel
40-pin connector on PCI local bus
Floppy drive
34-pin connector
2
Present only on computers with built-in audio capabilities.
Audio
3
Audio controller
Analog Devices AD1885 AC97 Codec
3
Present only on computers with built-in audio capabilities.
Video
Video controller
AGP 4X
Controls and Lights
Power control
push button
Power light
green light on power button—blinking green in sleep
state; solid green for power on state
Hard-drive access light
green
Diagnostic code lights
four bicolor (amber and green) located on back panel
Power
DC power supply:
Wattage
180 W
Heat dissipation
500 BTU (fully-loaded computer without monitor)
Voltage (see "Safety Instructions" for
important voltage setting information)
90 to 135 V at 50/60 Hz; 180 to 265 V at 50/60 Hz;
100 V at 50/60 Hz for Japanese computers
Backup battery
3-V CR2032 coin cell
Physical
Height x Width x Depth
10.6 x 38.9 x 43.2 cm
(4.2 x 15.3 x 17 inches)
Weight
9.9 kg (22 lb)
Environmental
Temperature:
Operating
10º to 35ºC (50º to 95ºF)
4
Storage
–40º to 65ºC (–40º to 149ºF)
Relative humidity
20% to 80% (noncondensing)
Maximum vibration:
Operating
0.25 G at 3 to 200 Hz at 1/2 octave/min
Storage
0.5 G at 3 to 200 Hz at 1/2 octave/min
Maximum shock:
Operating
bottom half-sine pulse with a change in velocity of
50.8 cm/sec (20 inches/sec)
Storage
23-G faired-square wave with a velocity change of
508 cm/sec (200 inches/sec)
Altitude:
Operating
–15.2 to 3048 m (–50 to 10,000 ft)
4
