Dell Dimension 4300S - DC Power Connector P6; DC Power Connector P5

DC Power Connector P6


DC Power Connectors P2, P3, and P4


DC Power Connector P5

Back to Contents Page


13
COM
Black
14
PS ON
1
Green
15
COM
Black
16
COM
Black
17
COM
Black
18
N/C
N/C
19
+5 VDC
Red
20
+5 VDC
Red
1
Use 22-AWG wire instead of 18-AWG wire
Pin Number
Signal Name
18-AWG Wire
1
COM
Black
2
COM
Black
3
+12 VDC
Yellow
4
+12 VDC
Yellow
Pin Number
Signal Name
18-AWG Wire
1
+12 VDC
Yellow
2
COM
Black
3
COM
Black
4
+5 VDC
Red
Pin Number
Signal Name
22-AWG Wire
1
+5 VDC
Red
2
COM
Black
3
COM
Black
4
+12 VDC
Yellow
