Dell E156FPc
24
Remove the shield :
1. Remove the screw by Torque
B or by manual and remove the
shield ,then remove the back
light connector
Remove the connector
Remove the two screws by
manual or torque = 3kgF.Cm and
remove the main frame
Remove the main frame and at
the same time disconnect the
LVDS connector and remove the
EVA washers
To Next Page
