5.3 Electrical Block Diagram
5.3.1 Main Board
H-sync,
V-sync
RGB
OSD
Control
Interface
(CN101)
Scalar GmZan3-SL
(Include ADC, Scalar, OSD)
(U102)
MCU
Win Bond W78E65
(SyncMos SM5964)
(U101)
EEPROM
M24C16
(U104)
D-Sub
Connector
(CN100)
EEPROM
24C02
(U103)
RXD
TXD
DB12_SDA,
DB15_SCL
NVRAM_SDA
NVRAM_SCL
LCD Interface
(CN103)
LCD Panel
