Page #9 background imageLoading...
Page #9 background image
Back to Contents Page
Specifications: Dell™ E173FP Flat Panel Color Monitor User's
Guide
GeneralFlat PanelResolutionPreset Display ModesElectricalPhysical CharacteristicsEnvironmental Power
Management ModesPin AssignmentsPlug and Play Capability
General
Model number E173FP
Flat Panel
Screen type Active matrix - TFT LCD
Screen dimensions Diagonal 17 inches (432.0 mm)
Horizontal 13.3 inches (337.9 mm)
Vertical 10.6 inches (270.3 mm)
Pixel pitch
0.264 x 0.264
mm
Viewing angle
120
° (vertical) typical, 140° (horizontal) typical
Luminance output
250 cd
/m
2
typical
Contrast ratio
45
0 : 1 typical
LCD surface coating Hardness 3H, antiglare treatment
Backlight 4 CCFL type
Response time
16
ms
Resolution
Horizontal scan range 31 kHz to 80 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Optimal preset resolution 1280 x 1024 at 60 Hz
Highest preset resolution 1280 x 1024 at 75 Hz
