Drives
Hard drives
Four–hard-drive systems Up to four 3.5 inch, internal, cabled SATA, or
nearline SAS hard drives.
Eight–hard-drive systems Up to eight 3.5 inch, internal, hot-swappable SATA,
or nearline SAS hard drives.
NOTE: 2.5 inch hard drives in 3.5 inch carriers
are supported for SAS, and SATA SSD hard
drives.
Sixteen–hard-drive systems Up to sixteen 2.5 inch, internal, hot-swappable
SATA, nearline SAS, SAS, or SATA SSD hard drives.
Optical drive One optional SATA DVD-ROM drive or DVD+/-RW
drive.
NOTE: If your system is installed with a
double-width GPU card, the system supports
only one 5.25 inch removable media storage
device.
Tape drive Up to two optional 5.25 inch tape drive.
NOTE: If your system is installed with a
double-width GPU card, the system supports
only one 5.25 inch removable media storage
device.
Connectors
Back
NIC Two 10/100/1000 Mbps
Serial DB-9 Serial Port connector
USB Six Hi-Speed USB Host (five USB 2.0 and one USB
3.0)
Video 15-pin VGA
iDRAC8 One optional 1 GbE Ethernet
SD vFlash One optional SD vFlash memory card
Front
USB Two Hi-Speed USB Host (One USB 2.0 and one USB
3.0)
Video 15-pin VGA
NOTE: The front VGA port is available only with
the rack configuration.
