Expanded Operating Temperature
• Non-redundant power supplies are not
supported.
• Cabled power supply units are not supported.
• Non Dell qualified peripheral cards and/or
peripheral cards greater than 25 W are not
supported.
Environmental
NOTE: For additional information about environmental measurements for specific system
configurations, see dell.com/environmental_datasheets.
Temperature
Maximum Temperature Gradient (Operating and
Storage)
20 °C/h (36 °F/h)
Storage Temperature Limits –40 °C to 65 °C (–40 °F to 149 °F)
Relative Humidity
Storage 5% to 95% RH with 33 °C (91 °F) maximum dew
point. Atmosphere must be non-condensing at
all times.
Temperature (Continuous Operation)
Temperature Ranges (for altitude less than 950 m
or 3117 ft)
10 °C to 35 °C (50 °F to 95 °F) with no direct
sunlight on the equipment.
Humidity Percentage Range 10% to 80% Relative Humidity with 29 °C (84.2
°F) maximum dew point.
Maximum Vibration
Operating 0.26 G
rms
at 5 Hz to 350 Hz (all operation
orientations).
Storage 1.88 G
rms
at 10 Hz to 500 Hz for 15 min (all six
sides tested).
Maximum Shock
Operating Six consecutively executed shock pulses in the
positive and negative x, y, and z axes of 40 G for
up to 2.3 ms.
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse
on each side of the system) of 71 G for up to 2
ms.
Maximum Altitude
Operating
3,048 m (10,000 ft)
Storage 12,000 m (39,370 ft).
176
