Figure 16. 5G cable routing
Table 4. 5G cable routing
Antenna Function Cable length (cm)
ANT1 5G FR1 TX/RX 10
ANT4 LTE/5G RX 20
ANT5 LTE/5G RX 30
ANT6 5G FR1 TX/RX 30
Installation procedure for 4G and 5G expansion modules 13
