Dell EMC VxFlex Ready Node - Management Network A, Nodes 17 - 22 Cabling

Table 9 Management A, nodes 1 -16 cabling (continued)
Source Destination
Node 5 BMC (iDRAC) Management SwitchA Port 18
Node 5 MGMT1 Management SwitchA Port 20
Node 6 BMC (iDRAC) Management SwitchA Port 22
Node 6 MGMT1 Management SwitchA Port 24
Node 7 BMC (iDRAC) Management SwitchA Port 26
Node 7 MGMT1 Management SwitchA Port 28
Node 8 BMC (iDRAC) Management SwitchA Port 30
Node 8 MGMT1 Management SwitchA Port 32
Node 9 BMC (iDRAC) Management SwitchA Port 34
Node 9 MGMT1 Management SwitchA Port 36
Node 10 BMC (iDRAC) Management SwitchA Port 1
Node 10 MGMT1 Management SwitchA Port 3
Node 11 BMC (iDRAC) Management SwitchA Port 5
Node 11 MGMT1 Management SwitchA Port 7
Node 12 BMC (iDRAC) Management SwitchA Port 9
Node 12 MGMT1 Management SwitchA Port 11
Node 13 BMC (iDRAC) Management SwitchA Port 13
Node 13 MGMT1 Management SwitchA Port 15
Node 14 BMC (iDRAC) Management SwitchA Port 17
Node 14 MGMT1 Management SwitchA Port 19
Node 15 BMC (iDRAC) Management SwitchA Port 21
Node 15 MGMT1 Management SwitchA Port 23
Node 16 BMC (iDRAC) Management SwitchA Port 25
Node 16 MGMT1 Management SwitchA Port 27
Data SwitchA <...> Port Management SwitchA Port 45
Data SwitchB <...> Port Management SwitchA Port 46
Data SwitchA MGMT Port Management SwitchA Port 47
Data SwitchB MGMT Port Management SwitchA Port 48
Management Server NIC1 Management SwitchA Port 38
Link to Core Switch or Management SwitchB Management SwitchA Port 52
Management network A, nodes 17 - 22 cabling
Use the following table to connect cables for management network A, nodes 17 - 22.
Install Management Network I/O Cables
46 Dell EMC VxFlex Ready Node Server Installation Guide
