PowerEdge R210 Technical Guide 16
4 Mechanical
4.1 Chassis Description
The PowerEdge R210 is a 1-socket 1U server. The configuration details are as follows:
• HDD Type : 2x 3.5” Cabled HDD or 2 x 2.5” cabled HDD
• PSU Type: Single Non-Redundant PSU
• Diagnostic: LED
4.2 Dimensions and Weight
Table 5. Overall Dimensions and Weight
Dimensions (HxWxD)
(w/o ear and bezel)
1.68” x 17” x 15.5”
(42.6 x 431 x 393.7 mm)
Max Weight 17.76 lbs (8.058kg)
Measurements in Table 6 correspond to the diagram shown in Figure 1 below.
Table 6. Specific Measurements
Xa Xb Ya Yb Yc
Za
with bezel
Za
without
bezel Zb* Zc
L6 Sys
Wgt
(Kg)
434.0
482.58
42.4
N/A
N/A
31.35
NA
393.7
397.49
5.95
