PowerEdge R210 Technical Guide 45
• Core Addressing Mapping, Intel VT-d, System Management
• Core Semaphore and Scratchpad Registers
• Core System Control/Status Registers
• Core Miscellaneous Control/Status Registers
• Intel QuickPath Interconnect Link
• Intel QuickPath Interconnect Routing and Protocol
Core i3/Pentium/Celeron CPU PCI devices include:
• Host Bridge/DRAM Controller
• Host-to-PCI Express Bridge
• Internal Graphics Device
• Secondary Host–to-PCI Express Bridge
PCH and Slots devices include:
• Virtualization Engine Controller Interface (VECI)
• USB HS EHCI Controller #2
• PCI Express Port 1
• PCI Express Port 2
• PCI Express Port 3
• PCI Express Port 4
• PCI Express Port 5
• PCI Express Port 6
• PCI Express Port 7
• PCI Express Port 8
• USB HS EHCI Controller #1
• DMI-to-PCI Bridge
• LPC Controller1
• SATA Controller #1
o Non-AHCI and Non-RAID Mode (Ports 0,1, 2 and 3)
o Desktop Non-AHCI and Non-RAID Mode (Ports 0 and 1)
o AHCI Mode (Ports 0-5)
o AHCI Mode (Ports 0,1,4 and5)
o RAID 0/1/5/10 mode
• SMBus Controller
• SATA Controller #2
o Non-AHCI and Non-RAID Mode (Ports 4 and 5)
• Thermal Subsystem
• Slot 1 PCI-E x16 [IIO]
• BCM5716 (1)
• BCM5716 (2)
• Matrox
®
G200eW w/ 8MB memory
The onboard devices are SATA, USB (x4), SMBus, IOxAPIC, and the LOM.
Table 17. I/O Slot Information
PCI Slot # Mechanical Electrical Height Length
1 PCIe x 16 PCIe x 16 Gen 2 Full Half
