Removing the base cover
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Remove the 10 screws (M2.5x7) that secure the base cover to the palm rest and keyboard assembly.
2 Loosen the two captive screws (M2.5) on the base cover.
3
Pry the base cover starting from the left hinge.
4 Continue prying the base cover from the bottom of the computer base.
3
Removing the base cover 13
