Removing the display back-cover and antenna
assembly
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the display assembly.
4 Remove the display bezel.
5 Remove the camera.
6 Remove the display panel.
7 Remove the display hinges.
8 Remove the display cable.
Procedure
After performing all the above steps, we are left with the display back-cover and antenna assembly.
51
Removing the display back-cover and antenna assembly 83
