Removing the display panel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the display assembly.
4 Remove the display bezel.
Procedure
1 Remove the four screws (M2x3) that secure the display panel to the display back-cover and antenna assembly.
2 Lift the display panel and turn it over.
3 Peel the tape adhering the display cable to the back of the display panel.
4 Open the latch and disconnect the display cable from the display-panel cable connector.
5 Lift the display panel away from the display back-cover and antenna assembly.
45
Removing the display panel 75
