Dell G3223D - Side View; Bottom View

About your monitor │ 13
Side view
Bottom view
6
1
54
7
8 9 10
2
3
Bottom view without monitor stand
Label Description Use
1 Power connector Connect the power cable (shipped with your
monitor).
2 Security-lock slot
(based on Kensington
Security Slot)
Secure your monitor using a security lock
(purchased separately) to prevent unauthorized
movement of your monitor. For more information,
see Securing your monitor using Kensington lock
(optional).
3 Stand lock feature To lock the stand to the monitor using a M3x6
mm screw (screw not included).
4 HDMI 2.0 port Connect to your computer using an HDMI cable.
5 HDMI 2.0 port Connect to your computer using an HDMI cable.
6 DisplayPort 1.4 Connect to your computer using a DisplayPort
cable.
