34 │ Setting up the monitor
3. Lift the stand up and away from the monitor.
Wall mounting (optional)
NOTE: Use M4x10 mm screws to connect the monitor to the wall-
mounting kit.
Follow the instructions that come with the VESA-compatible wall mounting kit.
1. Place the monitor on a soft cloth or cushion on a stable flat table.
2. Remove the stand. For more information, see Removing the monitor stand.
3. Remove the four screws that secure the display back cover.
4. Attach the mounting bracket from the wall mounting kit to the monitor.
5. Mount the monitor on the wall as instructed in the documentation that shipped
with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket
with minimum weight or load bearing capacity of 22.88 kg (50.44 lb).
