Setting up the monitor │ 27
Setting up the monitor
Attaching the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for the stand that
was shipped with your monitor. If you are attaching a stand that you
purchased from any other source, follow the setup instructions that
were included with the stand.
1. Follow the instructions on the flaps of packaging box to remove the stand from
the top cushion that secures it.
2. Align and place the stand riser on the stand base.
3. Open the screw handle at the bottom of the stand base and turn it clockwise
to secure the stand assembly.
4. Close the screw handle.
3
2
1
4
5. Open the protective cover on the monitor to access the VESA slot on the
monitor.
