Dell G3223D - Page 47

Operating your monitor │ 47
Icon Menu and
submenus
Description
PIP/PBP Enables you to watch more images at the same time.
Dell 32 Gaming Monitor
Personalize
Audio
Display
Others
Menu
PIP/PBP
G3223D
Game
Input Source
Brightness / Contrast
PIP/PBP Mode O
PIP/PBP Mode Adjusts the PIP or PBP mode. You can adjust this
feature by selecting Off, 50%-50%, 75%-25%,
25%-75%, 67%-33%, 33%-67%, PIP(Small),
PIP(Large).
NOTE: FreeSync is turned off when PIP/PBP
is enabled.
PIP/PBP (Sub)
Selects between USB-C 15W, DP, HDMI 1, or
HDMI 2 video signals that may be connected to your
monitor for the PIP/PBP sub-window.
Main Window
Sub-Window
USB-C 15W
DP HDMI 1 HDMI 2
USB-C 15W
DP
HDMI 1
HDMI 2
Audio Enables you to set the Audio Main or Sub.
Video Swap Selects to swap videos between main window and
sub-window in PIP/PBP mode.
Contrast (Sub) Adjust the contrast level of the picture in PIP/PBP
mode.
NOTE: Only applicable when you turn on
PIP/PBP.
