Dell IN2030M - Flat Panel Specifications; Resolution Specifications; Electrical Specifications

Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor automatically provides the computer with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so that the
system can configure itself and optimize the monitor settings. Most monitor installations are automatic. You can select different settings if required.
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Flat Panel Specifications
* Based on estimation.
** [IN1930/IN2030M] color gamut (typical) is based on CIE1976 (82 %) and CIE1931 (72 %) test standards.
Resolution Specifications
Electrical Specifications
Model number
Dell IN1930 monitor
Dell IN2030M monitor
Screen type
Active matrix - TFT LCD
Active matrix - TFT LCD
Panel Type
TN
TN
Screen dimensions
47.0 cm (18.5 inches) (18.5-inch wide
viewable image size)
50.8 cm (20 inches) (20-inch wide
viewable image size)
Preset display area:
l Horizontal
l Vertical

409.8 mm (16.14 inches)
230.4 mm (9.07 inches)

442.8 mm (17.43 inches)
249.1 mm (9.81 inches)
Pixel pitch
0.300 mm
0.277 mm
Viewing angle:
l Horizontal
l Vertical

170°typical
160°typical

170°typical
160°typical
Luminance output
250 cd/m² (typical)
250 cd/m² (typical)
Contrast ratio
1000 to 1 (typical)
1000 to 1 (typical)
Dynamic Contrast Ratio
8,000,000 to 1 (typical) *
8,000,000 to 1 (typical) *
Faceplate coating
Antiglare with hard-coating 3H
Antiglare with hard-coating 3H
Backlight
LED light bar system
LED light bar system
Response Time
5 ms typical (black to white)
5 ms typical (black to white)
Color Depth
16.7 mil colors
16.7 mil colors
Color Gamut
82 % (typical) **
82 % (typical) **
Model number
Dell IN1930 monitor
Dell IN2030M monitor
Scan range
l Horizontal
l Vertical

30 kHz to 83 kHz (automatic)
56 Hz to 75 Hz (automatic)

30 kHz to 83 kHz (automatic)
56 Hz to 75 Hz (automatic)
Maximum preset resolution
1366 x 768 at 60 Hz
1600 x 900 at 60 Hz
Model number
Dell IN1930/IN2030M monitor
Video input signals
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical
synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage / frequency / current
100 VAC to 240 VAC/50 Hz or 60 Hz + 3 Hz/1.5 A
(Max.)
