Display 63
Replacing the Display Bezel
1
Follow the instructions in "Before You Begin" on page 9.
2
Realign the display bezel over the display panel and gently snap into place.
3
Replace the display assembly (see "Replacing the Display Assembly" on
page 61).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Panel
Removing the Display Panel
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 59).
3
Remove the display bezel (see "Removing the Display Bezel" on page 62).
4
Disconnect the camera cable from the connector on the camera module
(see "Removing the Camera Module" on page 69).
5
Make a note of the display cable and Mini-Card antenna cables routing
and remove them from the routing guides on the display hinges.
6
Remove the six screws that secure the display panel to the display cover.
1 display bezel
