Steps
1. Place the battery on the palm-rest assembly.
NOTE:
Ensure that the battery cable is not under the battery when placing the battery on the palm-rest assembly to
avoid damage to your computer.
2. Align the screw holes on the battery to the screw holes on the palm-rest assembly.
3. Replace the four screws (M2x3) that secure the battery to the palm-rest assembly.
4. Adhere the tapes that secure the battery to the palm-rest assembly.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Solid-state drive/Intel Optane
Removing the M.2 2230 solid-state drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: This procedure applies only to computers shipped with a M.2 2230 solid-state drive installed.
NOTE: The M.2 card installed on your computer will depend on the configuration ordered. Supported card configurations on
the M.2 card slot:
Removing and installing components 17
