Quick Reference Guide 13
Back View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air
vents. Do not store your computer in a low-airflow environment, such as a closed
briefcase, while it is running. Restricting the airflow can damage the computer or
cause a fire.
1 network connector
(RJ-45)
4 video connector 7 AC adapter connector
2 modem connector
(RJ-11)
5 powered USB
connector
3 USB connectors (2) 6 IEEE 1394 Connector
712 3 4 5 6
