Installing the optional PCIe SSD
1. Insert the SSD clip into the slot on the computer.
2. Tighten the screw to secure the SSD clip to the computer.
3. Insert the SSD into the connector on the computer.
4. Place the SSD bracket over the SSD and tighten the screws to secure it to the computer.
5. Install the:
a. battery
b. base cover
6. Follow the procedure in After working inside your computer.
Installing the Solid State Drive (SSD)
1. Insert the SSD into the connector on the computer.
2. Tighten the screw to secure the SSD to the computer.
3. Install the:
a. battery
b. base cover
4. Follow the procedure in After working inside your computer.
Removing the memory module
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. Pull the clips securing the memory module until the memory module pops up [1].
4. Remove the memory module from the system board [2].
13
