Dell Latitude E7470 - Installing the Dock Frame; Removing the Coin Cell Battery

Installing the dock frame
1. Place the dock frame on the computer.
2. Tighten the screws to secure the dock frame to the computer.
3. Install the:
a. battery
b. base cover
4. Follow the procedure in After working inside your system.
Removing the coin cell battery
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. To remove the coin cell battery:
a. Disconnect the coin cell battery cable from the connector on the system board [1].
b. Lift the coin cell battery to release it from the adhesive and remove it from the system board [2].
16
