Small Desktop System Board Screws
Place the system board assembly that you just removed next to the replacement system board to ensure it is identical.
Replacing the System Board
1. Gently align the board into the chassis and slide it toward the back of the computer.
2. Replace the screws on the system board.
3. Replace any components and cables that you removed from the system board.
4. Reconnect all cables to their connectors at the back of the computer.
5. Replace the computer cover.
