Dell OptiPlex 3070 Small Form Factor Setup And Specifications

Tower/Small form factor/Micro
802.3az-2010. (required for
California Energy Commission
MEPs)
External ports and connectors
NOTE: Tower supports Full Height (FH) cards and Small Form Factor supports Low Prole (LP) cards. See chassis diagrams
section for port/connector locations.
Table 12. External ports / connectors
Tower Small Form Factor Micro
USB 2.0 (Front/Rear/Internal) 2/2/2 2/2/2 0/2/0
USB 3.1 Gen 1 (Front/Rear/Internal) 2/2/0 2/2/0 2/2/0
Serial
Parallel/Serial PCIe card
or PS/2/Serial add-in
bracket (Optional)
Low Prole Serial PCIe card or
PS/2 & Serial port add in bracket
(Optional)
• Available in 2 options
– Serial port
(Optional)
– Serial and PS/2 via
fan out cable
(Optional)
Network Connector (RJ-45) 1 Rear 1 Rear 1 Rear
Video:
DisplayPort 1.2 1 Rear 1 Rear 1
HDMI 1.4 port 1 Rear 1 Rear 1 Rear
Support for Dual 50W Graphics No No No
Support for Dual 25W Graphics No No No
Integrated Graphics output -
3rd optional video out: VGA, DP, or HDMI
2.0b
Optional Optional Optional
Audio:
Line out for headphones or speakers 1 Rear 1 Rear 1 Front
Universal Audio Jack 1 Front 1 Front 1 Front
System board connectors
NOTE
: See Detailed Engineering Specications for maximum card dimensions.
Table 13. System board connectors
Tower Small Form Factor Micro
PCIe x16 Slot(s)
1
1 1 0
PCIe x1 Slot(s) 3 1 0
Serial ATA (SATA)
2
3 2 1
M.2 Socket 3
3
(for SSD) 1 - 2230/2280 1 - 2230/2280 1 - 2230/2280
16 System specications
