Dell OptiPlex 320 - Advanced Features; LegacySelect Technology Control; Manageability; Security Features

Dell™ OptiPlex™ 320
Tech Specs
MINITOWER
DESKTOP
HARD DRIVE OPTIONS
Supported Types Serial ATA or Serial ATA 3.0
Available Drives 7200RPM SATA 3.0Gb/s: 40GB, 80GB, 160GB
SMART Technology SMART III
Burst Transfer Rate 300 Mbit/s
Partition Support MS Windows XP Professional SP2: Support both FAT16 and FAT32. FAT32 will be the default configuration
MS Windows XP Home SP2: Support both FAT16 a
SYSTEM BOARD CONNECTORS
Primary IDE drive 40-pin connector
Serial ATA four 7-pin connectors
Floppy drive 34-pin connector
Serial 12-pin connector for optional second serial port card
Fan 5-pin connector
PCI 2.2 120-pin connector
CD drive audio interface 4-pin connector
Front panel 40-pin connector
STANDARD I/O PORTS
* Front ports may be disabled
Display Port 1 VGA Out (15-hole)
USB 2.0 Two front and four rear
Serial Port One, rear. A second serial port is optional. (9-pin, 16550 compatible)
Parallel Port One, rear (25-hole, bi-directional)
Ethernet Network One, rear (RJ45)
Stereo line-in One minijack, rear
Speakers, line-out One minijack, rear
Microphone-in None
Headphone One minijack, front
Optional Adapters Optional PS/2, Serial
COMPUTER INFORMATION
System Clock Utilizes the CK-410 clock synthesizer chip, which incorporates Intel specifications for clock generation
Data bus width 64 bits
Address bus width 32 bits
DMA channels eight
Interrupt levels 24
EXPANSION BUS INFORMATION
PCI 2.3 PCI: 33 MHz
PCI Express 1.0a PCI Express x16: 80 Gbps
SATA 1.0a and 2.0 SATA: 3.0 Gbps
USB 2.0 USB: 480 Mbps
PCI
Available slots Two Full-Height Two Low-Profile
Connector size 120 pins
Data Bus 32Bit/33MHz
Voltage 3.3 Volt External Operation (some pins 5 Volt Tolerant); 1.8V internal regulation
PCI Express x16
Available slots One Full-Height One Low-Profile
Connector Size 164 pins
Data Bus 16 bi-directional differential lane pair (2.5Gb/s per lane) 40Gb/s total
Voltage 12V
Power 25 W maximum
