Dell OptiPlex 390 Mini-Tower - Input;Output Panel; Removing the Input;Output Panel

Input/Output Panel 15
Removing the Input/Output Panel
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the cover .
3. Remove the front bezel .
4. Disconnect the Input/Output Panel and FlyWire cable from the system
board.
5. Unthread the Input/Output Panel and FlyWire cable from the clip on the
computer.
6. Remove the screw that secures the Input/Output panel to the computer.
43
