Dell OptiPlex 5060 - Hard Drive and Optical Drive Module Installation

Installing the hard drive and optical drive module
1 Insert the tabs on the hard drive and optical drive module into the slot on the system at 30 degree angle [1].
2 Connect the optical drive data cable and power cable to the connectors on the optical drive [2, 3].
