Installing the fixed stand
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image provides a visual representation of the fixed stand installation procedure.
Steps
Align and insert the hooks on the mounting bracket on the stand into the slots on the monitor, until you hear a click.
Next steps
1. Follow the procedure in After working inside your computer.
Removing the height adjustable stand
Prerequisites
NOTE: Follow the same procedure to remove the Height Adjustable Stand with Optical Disk Drive.
1. Follow the procedure in Before working inside your computer.
CAUTION:
When servicing the system, place it on an elevated, clean, and flat surface. Dell recommends
removing the stand to avoid accidental damage to the system display during servicing.
Removing and installing components 15
