Installing the system board
1. Hold the system board by its edges and angle it toward the back of the computer.
2. Lower the system board into the computer until the connectors at the back of the system board align with the slots on the back
wall of the computer, and the screw holes on the system board align with the standos on the computer
3. Tighten the screws to secure the system board to the computer.
4. Place the metal tab on the system board and tighten the screw to secure the metal tab to the system board.
5. Install the:
a. processor
b. heat sink
c. system fan
d. VGA board
e. hard drive assembly
f. cover
6. Follow the procedure in After Working Inside Your Computer.
