Installing coin cell battery
Steps
1. Hold the coin cell battery with the "+" sign facing up and slide it under the securing tabs at the positive side of the
connector.
2. Press the battery into the connector until it locks into place.
3. Install the cover.
4. Follow the procedure in After working inside your computer.
Storage
Removing 2.5–inch drive assembly
Steps
1. Follow the procedure in Before working inside your computer.
2. Remove the cover.
3. To remove the drive assembly:
a. Press the blue tabs on both sides of the drive assembly [1].
b. Push the drive assembly to release it from the computer [2].
c. Remove the drive assembly from the computer [3].
Disassembly and reassembly
13
