4. Install the:
a. Heat sink assembly
b. Hard drive and optical drive module
c. HDD assembly
d. Front bezel
e. Side cover
5. Follow the procedure in After working inside your computer.
M.2 PCIe SSD
Removing the M.2 PCIe SSD
NOTE: The instructions are applicable to M.2 SATA SSD also.
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. Side cover
b. Front bezel
c. HDD assembly
d. Hard drive and optical drive module
e. Heatsink assembly
52
Removing and installing components
