Dell OptiPlex 790 - System Fan; Removing the System Fan

System Fan 13
Removing the System Fan
1. Follow the procedures in
Before Working Inside Your Computer .
2. Remove the
cover .
3. Remove the front bezel .
4. Remove the drive cage .
5. Remove the fan shelter .
6. Disconnect the fan cable from the system board.
7. Slide the grommets inward along the groove and pass through the chassis.
8. Lift and remove the system fan from the computer.
35
