Drives
Small Form Factor one
Ultra Small Form Factor none
2.5–inch SATA drive bays
Mini-Tower two
Desktop one
Small Form Factor one
Ultra Small Form Factor one
External Connectors
Audio:
Back Panel two connectors for line-out and line-in/
microphone
Front Panel two connectors for microphone and
headphone
Network Adapter one RJ45 connector
Serial one 9-pin connector; 16550C compatible
Parallel one 25-pin connector (optional for mini-
tower)
USB 2.0
Mini-Tower, Desktop, Small Form
Factor
Front Panel: 4
Back Panel: 6
Ultra Small Form Factor Front Panel: 2
Back Panel: 5
Video 15-pin VGA connector, 20-pin DisplayPort
connector
NOTE: Available video connectors may vary based on the graphics card
selected.
88
