14. Coin-cell battery
15. Speaker module
16. Fan
17. Power-button board
18. Fingerprint module
19. I/O board
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
NOTE: Before removing the base cover, ensure that there is no SD card installed in the SD card slot on your computer.
The following image(s) indicate the location of the base cover and provides a visual representation of the removal procedure.
Removing and installing components
13
