512 GB, M.2 2230, TLC PCIe NVMe Gen4, SED SSD (Opal certified)
The following table lists the M.2 2230, 1 TB SSD specifications.
Table 46. 512 SED SSD specifications
Description Values
Capacity 512 GB
Height (approximate) 2.38 mm (0.09 in.)
Width (approximate) 22 mm (0.87 in.)
Depth (approximate) 30 mm (1.18 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to four lanes)
MTBF 1.4M hours
Logical blocks 1,000,215,216
Power source
Power consumption (reference only)
● Idle: 5 mW (PS4)
● Active: 4 W
Environmental operating conditions (non-condensing)
Temperature range 0°C to 70°C
Relative humidity range 10% to 90%
Op shock 1500G
Environmental nonoperating conditions (non-condensing)
Temperature range -40°C to 70°C
Relative humidity range 5% to 95%
512 GB, M.2 2280, TLC PCIe NVMe Gen4, SSD
The following table lists the M.2 2280, 512 GB SSD specifications.
Table 47. 512 GB SSD specifications
Description Values
Capacity 512 GB
Height (approximate) 2.38 mm (0.09 in.)
Width (approximate) 22 mm (0.87 in.)
Depth (approximate) 80 mm (3.15 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to four lanes)
MTBF 1.4M hours
Logical blocks 1,000,215,216
Power source
Power consumption (reference only)
● Idle: 5 mW (PS4 - L1.2)
● Active: 5 W
Engineering specifications 43
