Table 49. 2 TB SSD specifications (continued)
Description Values
Height (approximate) 2.38 mm (0.09 in.)
Width (approximate) 22 mm (0.87 in.)
Depth (approximate) 80 mm (3.15 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to four lanes)
MTBF 1.4M hours
Logical blocks 4,000,797,360
Power source
Power consumption (reference only)
● Idle: 5 mW (PS4 - L1.2)
● Active: 5 W
Environmental operating conditions (non-condensing)
Temperature range 0°C to 70°C
Relative humidity range 10% to 90%
Op shock 1500G
Environmental nonoperating conditions (non-condensing)
Temperature range -40°C to 70°C
Relative humidity range 5% to 95%
Power adapter
The following table lists the power adapter specifications of your Precision 3590.
Table 50. Power adapter specifications
Description Option one Option two Option three
Type
65 W adapter, USB-C 100 W adapter, USB-C 130 W adapter, USB-C
Power-adapter dimensions:
Height
27.94 mm (1.10 in.) 26.41 mm (1.04 in.) 22.09 mm (0.87 in.)
Width
51.05 mm (2.01 in.) 59.94 mm (2.36 in.) 66.04 mm (2.60 in.)
Depth
112.01 mm (4.41 in.) 121.92 mm (4.80 in.) 143 mm (5.63 in.)
Input voltage
100 VAC-240 VAC 100 VAC-240 VAC 100 VAC-240 VAC
Input frequency
50 Hz-60 Hz 50 Hz-60 Hz 50 Hz-60 Hz
Input current (maximum)
1.70 A 1.70 A 1.80 A
Output current (continuous)
● 20 V/3.25 A (continuous)
● 15 V/3 A (continuous)
● 9 V/3 A (continuous)
● 5 V/3 A (continuous)
● 20 V/5 A (continuous)
● 15 V/3 A (continuous)
● 9 V/3 A (continuous)
● 5 V/3 A (continuous)
● 20 V/6.50 A (continuous)
● 5 V/1 A (continuous)
Rated output voltage
● 20 VDC ● 20 VDC ● 20 VDC
Engineering specifications 45
