Next steps
1. Install the 4G WWAN card or the 5G WWAN card, whichever applicable.
NOTE: This procedure applies only to computers shipped with a WWAN card installed.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Audio daughter-board
Removing the audio daughter-board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the 3-cell battery or the 4-cell battery, whichever applicable.
About this task
The following image indicates the location of the audio daughter-board and provides a visual representation of the removal
procedure.
Removing and installing components 61
