Dell P153G - Major Components of XPS 13 9315

Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Display-assembly
hinges
Palm-rest and keyboard
assembly
M1.6x2.5 2
Wireless-card bracket System board M1.6x2.3 1
System board Palm-rest and keyboard
assembly
M1.6x2.8 1
System board Palm-rest and keyboard
assembly
M1.6x1.5 5
System board Palm-rest and keyboard
assembly
M1.6x2.3 1
Major components of XPS 13 9315
The following image shows the major components of XPS 13 9315.
10 Removing and installing components
