● keyboard
● speakers
● wireless-antenna modules
● touchpad
The following image shows the palm-rest and keyboard assembly.
Steps
Place the palm-rest and keyboard assembly on a flat surface.
Next steps
1. Install the system board.
NOTE: The system board can be installed with the attached heat sink.
2. Install the I/O daughter-board.
3. Install the display assembly.
4. Install the fan.
5. Install the battery.
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Removing and installing components
37
